Guide of Smoke Curtain & Fire Curtain

Views: 59     Author: Site Editor     Publish Time: 2024-06-07      Origin: Site

Smoke curtains and fire curtains are critical components in fire safety and building design. Here’s a comprehensive guide to understanding their functions, types, installation, and maintenance.

Smoke Curtains



Smoke curtains are used to control the movement of smoke in the event of a fire. They help to contain and channel smoke, keeping escape routes clear and aiding in the effective operation of smoke ventilation systems.


1. Fixed Smoke Curtains: Permanently installed and often integrated into the building’s structure. They are typically used in areas where smoke control is a constant necessity.

2. Automatic Smoke Curtains: These are deployed automatically in the event of a fire. They can be hidden in ceilings or walls and drop down when activated by a fire alarm system.


· Location: Installed in strategic locations such as corridors, atria, and above doors to prevent smoke from spreading.

· Integration: Must be integrated with the building’s fire alarm system to ensure automatic deployment.

· Regulations: Installation must comply with local fire safety regulations and standards (e.g., EN 12101-1 in Europe, UL 1784 in the US).


· Regular Testing: Smoke curtains should be tested regularly to ensure they deploy correctly.

· Inspection: Periodic inspection for wear and tear, especially for the automatic mechanisms.

· Cleaning: Keeping them clean to avoid malfunction due to dust and debris.

Fire Curtains


Fire curtains are designed to contain and control the spread of fire. They create a barrier to stop fire from spreading to different parts of the building, providing time for evacuation and for the fire to be controlled.


1. Vertical Fire Curtains: Deploy vertically from the ceiling to the floor. Commonly used to protect doorways, windows, and open spaces.

2. Horizontal Fire Curtains: Deploy horizontally and are often used to protect skylights and atriums.

3. Egress Fire Curtains: Incorporate a built-in exit or door, allowing people to pass through while maintaining fire protection.


· Location: Installed in areas that require compartmentalization to prevent fire spread, such as elevator shafts, lobbies, and atria.

· Integration: Linked to the building’s fire detection system for automatic deployment.

· Regulations: Must comply with fire safety regulations and standards (e.g., BS 8524 in the UK, NFPA 80 in the US).


· Routine Testing: Fire curtains should be routinely tested to ensure they function correctly in the event of a fire.

· Inspection: Regular inspection for mechanical integrity and fabric condition.

· Servicing: Periodic servicing by qualified professionals to maintain operational readiness.

Key Considerations

Performance Ratings

· Fire Resistance: Fire curtains should have a fire resistance rating indicating the duration they can withstand fire exposure (e.g., 30, 60, 120 minutes).

· Smoke Control: Smoke curtains should have a rating that indicates their effectiveness in controlling smoke spread.

Integration with Building Systems

· Fire Alarm Systems: Both smoke and fire curtains need to be integrated with fire alarm and detection systems for automatic deployment.

· Emergency Lighting: Ensure proper lighting around curtains to help occupants see and use escape routes effectively.

Compliance and Certification

· Standards: Ensure compliance with relevant national and international standards.

· Certification: Use certified products and ensure installation is performed by certified professionals.


· Enhanced Safety: Both types of curtains significantly enhance the safety of building occupants by controlling smoke and fire spread.

· Flexibility in Design: Allows for open-plan designs while still meeting fire safety requirements.

· Cost-Effective: Can be more cost-effective than traditional fire barriers, such as walls and doors.


Smoke and fire curtains are essential for modern fire safety management, providing a flexible and effective solution to control the spread of smoke and fire within buildings. Proper selection, installation, and maintenance are crucial to ensure they perform as intended in an emergency. Always consult with fire safety experts and adhere to local regulations and standards when implementing these systems.
