In modern commercial fire safety engineering, controlling smoke movement is just as important as controlling fire itself. A properly designed smoke and fire curtain system plays a critical role in protecting evacuation routes, limiting fire spread, and improving overall building safety performance.
As a manufacturer with over 15 years of experience in fire protection systems, we specialize in producing high-performance automatic smoke and fire curtain solutions for global commercial and industrial projects.
Our systems are widely used in shopping malls, airports, metro stations, hotels, hospitals, and large warehouse facilities where open-space fire compartmentation is required.
What is a Smoke and Fire Curtain?
A smoke and fire curtain is a flexible, motorized fire barrier system designed to deploy automatically during fire emergencies. It remains hidden inside the ceiling during normal operation and drops down instantly when triggered by a fire alarm system.
Unlike traditional rigid fire doors, smoke curtains provide:
Large-span smoke compartmentation
Hidden architectural design integration
Flexible zoning for open spaces
Faster emergency response performance
This makes them an ideal solution for modern commercial architecture.
How Automatic Smoke and Fire Curtain Works
The automatic smoke and fire curtain system is connected to a building fire alarm or fire control system (FAS/BMS). Its working process includes:
Standby mode with curtain stored in headbox
Fire alarm signal activation
Automatic controlled descent by motor system
Formation of smoke barrier at preset height
Battery backup ensures operation during power failure
This ensures reliable performance even in extreme emergency conditions.
Technical Features & Specifications
Fire-Resistant Curtain Fabric
Fiberglass reinforced fireproof fabric
High temperature resistance up to 600°C
Fire ratings: 60 / 120 / 180 minutes
Optional smoke leakage control layer
Structural System
Galvanized steel or aluminum headbox
Side guide rail sealing system
Weighted bottom bar for stability
Concealed ceiling installation design
Control System
Automatic fire alarm integration
Smart control panel system
Emergency battery backup
Manual test and override function
Optional BMS integration
Size Range
Width: up to 6,000 mm (customized available)
Drop height: up to 6000 mm or project requirement
Applications
Our automatic smoke and fire curtain systems are widely installed in:
Shopping malls and retail centers
Airports and transportation hubs
Underground parking systems
Industrial warehouses
Hotels and commercial buildings
Hospitals and healthcare facilities
Exhibition halls and convention centers
High-rise office buildings
These environments require reliable smoke control systems to ensure safe evacuation and minimize fire damage.
OEM / ODM Customization Options
We provide full customization services for global distributors and contractors:
Fire rating customization (1–3 hours)
Fabric color options
Headbox structure design (exposed or concealed)
Motor voltage options (24V / 220V / 380V)
Control system integration (FAS / BMS)
Branding & OEM labeling
Special size engineering design
Factory Strength & Experience
With over 15 years of manufacturing experience, we have developed a stable and reliable production system for smoke control products.
15+ years fire curtain manufacturing experience
Dedicated production and testing lines
Strict quality inspection before shipment
Export experience to Middle East, Europe, Asia and Latin America
Engineering support for project approval
Every system is tested before delivery to ensure stable deployment performance.
Certifications & Compliance
Our smoke and fire curtain systems comply with international fire safety standards:
EN 12101-1 Smoke Control Systems
EN 1634-1 Fire Resistance Testing
CE Certification (project dependent)
BS 476 Fire Safety Standards
We provide full technical documents including drawings, wiring diagrams, and test reports for project approval.
Why Choose Us
15+ years professional experience in fire curtain systems
Factory direct pricing
OEM/ODM support for distributors
Fast production lead time (15–25 days)
Stable quality control system
Strong engineering support team
Global export experience
We are not just a supplier—we are a long-term technical partner for fire safety projects.
Installation & Maintenance
Our systems are designed for easy installation and long service life.
Pre-wired factory system for fast installation
Detailed installation manuals included
Remote technical support available
Low maintenance motor system
Regular testing capability for compliance
Inquiry Call to Action
If you are looking for a reliable automatic smoke and fire curtain manufacturer, we are ready to support your project from design to delivery.
We provide:
Fast quotation within 24 hours
Engineering drawings for approval
OEM branding support
Bulk order pricing for distributors
Technical consultation for projects
Contact us today with your project requirements, and our engineering team will recommend the most suitable smoke and fire curtain solution for your building.
